2025 Product Information

Standards & Options

Chassis

• Chassis: Spartan® K3 raised-rail chassis
• Engine: Cummins® 15 liter X15 turbocharged 605 HP engine with 1,950 lb. ft. torque at 1,150 RPM Transmission: Allison® 4,000 MH 6-speed transmission
• Radiator: Side-mounted, parallel-airflow radiator
• Alternator: 210 amp alternator
• Engine Block Heater: 1,500W engine block heater
• Engine Brake: Three-stage engine brake
• Front Axle: Meritor® front axle with independent front suspension, integrated anti-sway bar and custom-tuned Koni® shocks- 20,000 lb. rating
• Rear Axle: Dana® rear axle - 20,000 lb. rating
• Tag Axle: Reyco® Granning® passive-steer tag axle with onee-touch manual air dump - 14,000 lb. rating
• Braking System: All-wheel ABS disc brakes
• Rear Axle Ratio: 4.30 rear axle ratio
• Tires: Michelin® 365/70R 22.5 in. tires (front) and 315/80R 22.5 in. tires (rear)
• Tire Pressure Monitoring: Tire pressure monitoring system (TPMS) with temperature monitoring Traction Control: Automatic traction control
• Leveling System: Equalizer™ hydraulic automatic coach leveling
• Air Leveling: Valid™ Truline air leveling system with auxiliary air compressor
• Air Connection: Remote air connection
• Chassis Battery: (2) 12V chassis batteries
• Fuel Tank: 175 gal. fuel tank with dual fills DEF Tank 15 gal.
• DEF tank: with dual fills
• Tow Air Brake System: Spartan® Safehaul tow vehicle air brake system
• Hitch: 20,000 lb. hitch with 7-pin plug

Construction

• Roof: 4 in. arched aluminum trusses filled with batt insulation and reflective Flexfoil® topped with 3/8 in. plywood decking then one-piece fiberglass
• Walls: 2-1/2 in. exterior walls with Aluma-Tru™ welded tubular aluminum studs on 16 in. centers or less, filled with batt and Flexfoil® insulation, then covered with high-gloss gelcoat fiberglass (R-16)
• Floor: 2 in. x 4 in. wood trusses on 16 in. centers or less filled with batt and Flexfoil® insulation then topped with 3/4 in. 7-ply plywood decking (R-33)
• Frame: X-Bridge™ bracing welded into chassis frame
• Slideouts: Entegra-exclusive Relia-Torque flush-mounted 12V slideout system

Heat, AC, Water and Power

• Heated Tanks: Aqua-Hot® heated basement storage
• Generator: Onan® 12,500W diesel generator, with automatic start, on powered slide-out tray
• Batteries: (4) L16 AGM batteries (6V/390 amp hrs. ea.)
• Solar: (2) 200W solar panels
• Electrical Hookup: 50 amp power cord on electric powered reel
• Transfer Switch: Smart automatic transfer switch with surge protection
• Air Conditioning: (3) 15,000 BTU A/C units with heat pumps and condensation drain system
• Heating System: Aqua-Hot® 600D hydronic water and heating system with in-floor heat throughout and engine preheat
• Black Tank Management: Sani-Con® macerator holding tank dump system with power gate valves and manual backup
• Tank Flush: Black tank flush; Grey tank flush
• Tank Assist: Tilt tank dump
• Water Filtration: City and tank water filtration system
• Water Hook-Up: Hot and cold water hook-up in front cap area with 30 ft. quick-disconnect hose
• Water Hose w/ Electric Reel: Water hose with electric reel
• Inverter: Victron 3,000W pure sine wave inverter with LED screen
• Water Softner: Water softener prep in driver-side compartment

Exterior

• Front/Rear Cap: Insulated front and rear caps (R-24)
• Utility Center: Heated exterior utility center with 5 in. LED Firefly® tank monitoring panel
• Stainless Steel Accents: Executive Bus Armor 10 in stainless steel trim
• Engine Door: Power rear engine door with manual override
• Patio Awnings: Dual roof-mounted Girard® Vision dual-pitched patio awnings with LED lights
• Door Awning: Girard® power entrance door awning with LED lights
• Slideout Awnings: Girard® Ultra slideout awnings
• Window Awnings: Girard® Ultra power window awnings
• Windows: Frameless, dual-pane, tinted, safety-glass windows
• Keypad: Lit grab handle with doorbell and keypad system for keyless entry
• Entertainment: 43 in. Samsung® QLED 4K UHD Smart TV with tilt, swivel, and extend adjustment; JBL® radio and speakers with USB port and receptacle
• Mirrors: Blind-spot monitoring indicators in chrome, heated, remote-control side-view mirrors
• Exterior: Diamond Shield™ front protective film mask
• Headlights: Automatic LED high and low beam headlights
• Fog Lights: Halogen fog lights
• Daytime Running Lights: Automatic daytime running lights
• LED Lights: LED marker lights, turn lights, license plate light, third brake light, accent lights and docking lights
• Accent Lights: LED accent lights under all slideout rooms
• Lights: Porch light and motion sensor security lights
• Rear Mudflap: Mudflap with chrome “Entegra Coach” nameplate
• Satellite Internet: Starlink satellite internet system
• Satellite Dish - US: Winegard® TRAV’LER satellite dish DIRECTV® - standard with USA option
• Satellite Dish - CA: Winegard® TRAV’LER Pro satellite dish Shaw TV - standard with CSA option
• Antenna: Winegard® Rayzar Automatic powered TV antenna
• Wi-Fi: Winegard® WiFiRanger™ Wi-Fi extender
• Cargo Features: (2) power slideout basement storage trays
• Freezer: 2.8 cu. ft. exterior refrigerator/freezer on slideout tray
• Baggage Doors: Push-button, power-unlatching baggage doors with LED indicator light Exterior Walls Sikkens custom full-body paint
• Chrome Accents: LED-lit chrome clearance accent light
• Entrance Door: Removable screen on entry door

Cockpit

• Dash: Valid™ 15 in. digital dash with quad core graphics processor, on-board diagnostics and ability to display traditional instrument cluster, 360° camera system or GPS navigation
• Cameras: Delta Mobile Systems® aiDARS™ 1X active 360° surround view system with 14 smart radar sensors and 6 HD cameras displayed on digital dash screen
• Infotainment System(s): Valid™ infotainment system with 15 in. touchscreen, Sygic navigation, Bluetooth®, Sirius XM™ and AM/FM tuner, integrated camera control, house mode whole-coach audio distribution and integrated VegaTouch coach control
• Side Consoles: 4.3 in. infotainment control touchscreen in passenger console
• Driving Features: E-Z Steer™ adjustable power steering assist
• Steering Wheel: Leather steering wheel with integrated controls for screen selection, instrument cluster navigation, media source selection, cruise, wipers and Bluetooth® phone functionality
• Steering Column: Power tilt and telescoping steering column
• Sound System: JBL® premium audio 11-speaker sound system with amplifier, speakers and DVC subwoofer
• Antenna : All-in-one automotive antenna for AM/FM/Sirius/GPS dash radio system
• Windshield: Ultra-Vision® one-piece wrap-around tinted windshield; Rain-sensing windshield wipers
• Driver / Passenger Seats: Heated and cooled leather driver and passenger seats with powered 6-way adjustment, lumbar, recline, footrest and massage functions
• Power Features: Powered driver's window; Powered flush stepwell cover
• Pedals: Powered adjustable brake and accelerator pedals
• Visors & Privacy Shade: Powered front sun visors and privacy shades
• Collision Mitigation: Collision avoidance system with collision warning, adaptive cruise control and electronic stability control
• Additional Amenities : Bergstrom dual-zone HVAC system; Dual USB port and one 12V socket for charging

Interior

• Electric Fireplace: LED-lit fireplace with 5,000 BTU heating element (45B, 45Z)
• Television - Front Overhead: 32 in. Samsung® QLED 4K UHD Smart TV in front overhead
• Command Center: Firefly multiplex system with 10 in. VegaTouch touchscreen for complete integration of coach controls, with remote monitoring and control (mobile app available)
• Switches: Spyder 3.5 in. touchscreen switches throughout
• Television - Living Room: 50 in. Samsung® QLED 4K UHD Smart TV
• Sound - Living Room: Bose® sound bar with subwoofer and universal remote control
• DVD Systems: Sony® Blu-ray™ player
• Furniture: Premium leather Crown Compass furniture
• Flooring: Hand-laid porcelain tiled floors
• Lighting: LED interior lighting
• Ceiling: Decorative ceiling feature with integrated accent lighting
• Window Treatments: Powered solar day and blackout night shades
• Central Vacuuming System: Portable Shark® vacuum cleaner
• Interior Doors: Aire-Secure™ travel locks for all pocket doors
• Bar: Bar area with beverage chiller and rain glass upper cabinet door with LED accent lighting (45R only)
• Bunks: Bunks with industry-exclusive 300 lb. capacity each (45R)
• Washer/Dryer: Splendide stackable washer and dryer

Kitchen

• Window: Window with push out lever operation and screen
• Refrigerator: Stainless steel residential refrigerator
• Cooktop: Induction cooktop with matching wood cover
• Microwave: 1.9 cu. ft. convection microwave oven
• Dishwasher: Fisher & Paykel dishwasher
• Countertops: Solid-surface countertops with Blanco single-bowl granite sink and dimmable LED accent lighting
• Water Dispenser: Filtered water dispenser at kitchen sink
• Vent: Maxxair® power vent exhaust fan with intake and touch screen control
• Waste Basket: Large, deep drawer for waste basket with easy access trash chute (trash chute not available in 45D, 45R)
• Storage: Pantry with pull-out shelves; Slide-out storage tray(s) in overhead cabinet

Bedroom

• Bed: Personal Comfort® A5 king-size mattress
• Television: 32 in. Samsung® LED 4K UHD Smart TV
• Sound: Bose® sound bar with universal remote control
• DVD Systems: Sony® Blu-ray™ player
• Ceiling Fan: Ceiling fan
• Nightstands: Nightstands with solid-surface tops
• Wardrobe: Automatic light in rear closet

Bathroom

• Countertop(s): Solid-surface countertops with integrated glass sink and dimmable LED accent lighting
• Shower: Porcelain tile shower walls and floor with skylight and frameless glass shower door
• Shower Seat: Teakwood shower seat
• Shower Head: Pivoting shower head and separate hand-held spray wand
• Water Saving System: Aqua View SHOWERMI$ER™ water saving system
• Toilet: Thetford® macerator toilet in main bath; Thetford® macerator toilet in mid bath (45D, 45R, 45W); Thetford® Aria china toilet in mid bath (45B)
• Vent: Maxxair® Deluxe power exhaust vent fan with intake

Safety

• Carbon Monoxide Detector: Carbon monoxide detector
• Smoke Alarm: Smoke alarm
• Security Safe: Storage safe
