2024 Product Information

Standards & Options

Chassis

• Chassis: Spartan® K2 raised-rail chassis
• Engine: Cummins® L9 turbocharged 450 HP engine with 1,250 lb. ft. torque at 1,400 RPM
• Transmission: Allison® 3,000 MH 6-speed transmission
• Radiator: Side-mounted, parallel-airflow radiator
• Alternator: 170 amp alternator
• Engine Block Heater: 1,000W engine block heater
• Engine Brake: Three-stage engine brake
• Front Axle: Meritor® front axle with independent front suspension, integrated anti-sway bar and custom-tuned Koni® shocks- 20,000 lb. rating
• Front Suspension: Independent front suspension (IFS)
• Rear Axle: Meritor® rear axle - 20,000 lb. rating (N/A 37K); Hendrickson® rear axle - 24,000 lb. rating (37K)
• Tag Axle: Tag axle with one-touch manual air dump - 12,000 lb. rating (N/A 37K)
• Braking System: ABS disc brakes on front axle, drum brakes on drive and tag axle
• Rear Axle Ratio: 4.88 rear axle ratio
• Tires: Michelin® XZA 365/70R 22.5 in. tires (front) and XZA 315/80R 22.5 in. tires (rear)
• Tire Pressure Monitoring: Tire pressure monitoring system (TPMS) with temperature monitoring
• Traction Control: Automatic traction control
• Leveling System: Equalizer™ hydraulic automatic coach leveling
• Air Leveling: Valid™ Truline air leveling system with auxiliary air compressor
• Air Connection: Remote air connection
• Chassis Battery: (2) 12V chassis batteries
• Fuel Tank: 150 gal. fuel tank with dual fills
• DEF Tank: 15 gal. DEF tank with dual fills (single fill on 44D, 44R)
• Tow Air Brake System: Spartan® Safehaul tow vehicle air brake system
• Hitch: 15,000 lb. hitch with 7-pin plug
• Shocks: Custom-tuned Koni® shocks

• Roof: 4 in. arched aluminum trusses filled with batt insulation and reflective Flexfoil® topped with 3/8 in. plywood decking then one-piece fiberglass
• Walls: 2-1/2 in. exterior walls with Aluma-Tru™ welded tubular aluminum studs on 16 in. centers or less, filled with batt and Flexfoil® insulation, then covered with high-gloss gelcoat fiberglass (R-16)
• Floor: 2 in. x 4 in. wood trusses on 16 in. centers or less filled with batt and Flexfoil® insulation then topped with 3/4 in. 7-ply plywood decking (R-33)
• Frame: X-Bridge™ bracing welded into chassis frame
• Slideouts: Entegra-exclusive Relia-Torque flush-mounted 12V slideout system

• Heated Tanks: Aqua-Hot® heated basement storage
• Generator: Onan® 10,000W diesel generator, with automatic start, on powered slide-out tray
• Inverter: 3,000W pure sine wave inverter
• Batteries: (4) L16 AGM batteries (6V/390 amp hrs. ea.)
• Solar: (2) 200W solar panels
• Electrical Hookup: 50 amp power cord on electric powered reel
• Transfer Switch: Smart automatic transfer switch with surge protection
• Air Conditioning: (3) 15,000 BTU A/C units with heat pumps and condensation drain system
• Heating System: Aqua-Hot® 450D hydronic water and heating system with in-floor heat throughout and engine preheat
• Black Tank Management: Sani-Con® macerator holding tank dump system with manual gate valves and manual backup
• Tank Flush: Black tank flush; Grey tank flush
• Tank Assist: Tilt tank dump
• Water Filtration: City and tank water filtration system
• Water Hook-Up: Hot and cold water hook-up in front cap area with 30 ft. quick-disconnect hose
• Water Hose w/ Electric Reel: Water hose with electric reel

• Front/Rear Cap: Insulated front and rear caps (R-24)
• Stainless Steel Accents: Premier Bus Armor 8 in. stainless steel trim
• Engine Door: Power rear engine door with manual override
• Patio Awnings: Dual roof-mounted Girard® Vision dual-pitched patio awnings with LED lights
• Door Awning: Girard® power entrance door awning with LED lights
• Slideout Awnings: Girard® Ultra slideout awnings
• Window Awnings: Girard® Ultra power window awnings
• Windows: Frameless, dual-pane, tinted, safety-glass windows
• Keypad: Lit grab handle with doorbell and keypad system for keyless entry
• Entertainment: 43 in. Samsung® QLED 4K UHD Smart TV with tilt, swivel, and extend adjustment; JBL® radio and speakers with USB port and receptacle
• Mirrors: Chrome, heated, remote-control, side-view mirrors with blind-spot indicators
• Exterior: Diamond Shield™ front protective film mask
• Headlights: Automatic LED high and low beam headlights
• Fog Lights: Halogen fog lights
• Daytime Running Lights: Automatic daytime running lights
• LED Lights: LED marker lights, turn lights, license plate light, third brake light, accent lights and docking lights
• Accent Lights: LED accent lights under all slideout rooms
• Chrome Accents: LED-lit chrome clearance accent light
• Lights: Porch light and motion sensor security lights
• Rear Mudflap: Mudflap with chrome “Entegra” nameplate
• Satellite Internet Starlink satellite internet system
• Satellite Dish - US: Winegard® TRAV’LER satellite dish DIRECTV® - standard with USA option
• Satellite Dish - CA: Winegard® TRAV’LER Pro satellite dish Shaw TV - standard with CSA option
• Antenna: Winegard® Rayzar Automatic powered TV antenna
• Wi-Fi: Winegard® WiFiRanger™ Wi-Fi extender
• Utility Center: Heated exterior utility center with 5 in. LED SeeLeveL™ tank monitoring panel
• Cargo Features: (2) power slideout basement storage trays (single tray on 37K)
• Freezer: 2.8 cu. ft. exterior refrigerator/freezer on slideout tray
• Baggage Doors: Push-button, power-unlatching baggage doors with LED indicator light
• Exterior Walls: Sikkens custom full-body paint
• Entrance Door: Removable screen on entry door

• Additional Amenities: Bergstrom dual-zone HVAC system; Dual USB port and one 12V socket for charging
• Dash: Valid™ 15 in. digital dash with quad core graphics processor, on-board diagnostics and ability to display traditional instrument cluster, 360° camera system or GPS navigation
• Cameras: Delta Mobile Systems® aiDARS™ 1X active 360° surround view system with 14 smart radar sensors and 6 HD cameras displayed on digital dash screen
• Infotainment System(s): Valid™ infotainment system with 15 in. touchscreen, Sygic navigation, Bluetooth®, Sirius XM™ and AM/FM tuner, integrated camera control, house mode whole-coach audio distribution and integrated VegaTouch coach control
• Side Consoles: 4.3 in. infotainment control touchscreen in passenger console
• Driving Features: E-Z Steer™ adjustable power steering assist
• Steering Wheel: Leather steering wheel with integrated controls for screen selection, instrument cluster navigation, media source selection, cruise, wipers and Bluetooth® phone functionality
• Steering Column: Power tilt and telescoping steering column
• Sound System: JBL® premium audio 11-speaker sound system with amplifier, speakers and DVC subwoofer
• Antenna: All-in-one automotive antenna for AM/FM/Sirius/GPS dash radio system
• Windshield: Ultra-Vision® one-piece wrap-around tinted windshield; Rain-sensing windshield wipers
• Driver / Passenger Seats: Heated leather driver and passenger seats with powered 6-way adjustment, lumbar, recline and footrest functions
• Power Features: Powered flush stepwell cover
• Pedals: Powered adjustable brake and accelerator pedals
• Visors & Privacy Shade: Powered front sun visors and privacy shades

• Electric Fireplace: LED-lit fireplace with 5,000 BTU heating element (44B, 44Z)
• Television - Front Overhead: 32 in. Samsung® QLED 4K UHD Smart TV in front overhead
• Command Center: Firefly multiplex system with 10 in. VegaTouch touchscreen, for complete integration of coach controls, with remote monitoring and control (mobile app available)
• Switches: Spyder 3.5 in. touchscreen switches throughout
• Television - Living Room: 50 in. Samsung® QLED 4K UHD Smart TV
• Sound - Living Room: Bose® sound bar with subwoofer and universal remote control
• DVD Systems: Sony® Blu-ray™ player
• Furniture: Premium leather Crown Compass furniture
• Flooring: Hand-laid porcelain tiled floors
• Lighting: LED interior lighting
• Ceiling: Decorative ceiling feature with integrated accent lighting
• Window Treatments: Powered solar day and blackout night shades
• Central Vacuuming System: Central vacuum system
• Interior Doors: Aire-Secure™ travel locks for all pocket doors
• Bar: Bar area with beverage chiller and rain glass upper cabinet door with LED accent lighting (44R only)
• Washer/Dryer: Separate washer and dryer
• Bunks: Bunks with industry-exclusive 300 lb. capacity each (44R)

• Window: Window with push out lever operation and screen
• Refrigerator: Stainless steel residential refrigerator
• Cooktop: Induction cooktop with matching wood cover
• Microwave: 1.9 cu. ft. convection microwave oven
• Dishwasher: Fisher & Paykel dishwasher
• Countertops: Solid-surface countertops with dimmable LED accent lighting
• Sink: Blanco single-bowl granite sink
• Water Dispenser: Filtered water dispenser at kitchen sink
• Vent: Maxxair® power vent exhaust fan with intake and touch screen control
• Waste Basket: Large, deep drawer for waste basket with easy access trash chute (trash chute not available in 44D, 44R)
• Storage: Pantry with pull-out shelves; Slide-out storage tray(s) in overhead cabinet

• Bed: Personal Comfort® A5 king-size mattress
• Television: 32 in. Samsung® LED 4K UHD Smart TV
• Sound: Bose® sound bar with universal remote control
• DVD Systems: Sony® Blu-ray™ player
• Ceiling Fan: Ceiling fan
• Nightstands: Nightstands with solid-surface tops
• Wardrobe: Large cedar-lined wardrobe with automatic light

• Countertop(s): Solid-surface countertops with dimmable LED accent lighting
• Sink: Integrated sink
• Shower: Porcelain tile shower with skylight and clear glass shower door
• Shower Seat: Teakwood shower seat
• Shower Head: Fixed shower head and separate hand-held spray wand
• Water Saving System: Aqua View SHOWERMI$ER™ water saving system
• Toilet: Thetford® macerator toilet in main bath; Thetford® macerator toilet in mid bath (44D, 44R, 44W); Thetford® Aria china toilet in mid bath (44B)
• Vent: Maxxair® Deluxe power exhaust vent fan with intake

• Carbon Monoxide Detector: Carbon monoxide detector
• Smoke Alarm: Smoke alarm
• Security Safe: Storage safe
